Details of a Log Home
From the Designers |
|
|
|
* 1. VAPOR BARRIER |
* 2. CONCRETE FOOTING W/ REINFORCING BARS |
* 3. CONCRETE FOUNDATION W/REINFORCING BARS |
|
* 4. FOUNDATION VENT |
* 5. CONCRETE PAD FOOTING W/POST HOLDER |
6. DECK SUPPORT POST |
|
7. DECK BEAM |
8. DECK JOIST |
9. SMOOTH CEDAR DECKING |
|
10. FLOOR SUPPORT POST |
11. FLOOR JOIST |
12. 2x6 TREATED SILL (BOTTOM) |
|
12. 2x6 TREATED SILL (BOTTOM) |
13. 2x6 SILL (TOP) |
14. 2x6 T & G FLOOR DECKING |
|
15. ROUGH-CUT CEDAR TRIM |
16. FLASHING |
17. DOUGLAS-FIR LOG WALL |
|
16. FLASHING |
17. DOUGLAS-FIR LOG WALL |
18. FOAM GASKET BETWEEN LOGS |
|
* 19. EXTERIOR WOOD PRESERVATIVE |
20. ELECTRICAL OUTLET (PRE-DRILLED) |
21. WINDOW UNIT |
|
22. ROUGH-CUT CEDAR WINDOW & DOOR TRIM |
23. WINDOW & DOOR WRAP |
* 24. INTERIOR WALL FINISH |
|
* 25. PLUMBING & ELECTRICAL |
26. DOUBLE-LOG FLOOR BEAM |
27. LOG FLOOR JOIST |
|
28. LOG POST |
29. DOUBLE-LOG RIDGE BEAM |
30. LOG RAFTER |
|
31. LOG RAFTER BLOCKING |
32. LOG STAIRS (OPTIONAL) |
33. LOG RAILING (OPTIONAL) |
|
34. STUD-FRAMED WALL |
35. BATT INSULATION |
36. PLYWOOD SHEATHING |
|
37. BUILDING PAPER |
38. 1x8 CEDAR CHANNEL-SIDING |
39. 2x6 T&G ROOF DECKING |
|
40. 1x6 NAILERS |
41. 2" RIGID INSULATION |
42. SPACE-SHEATHING |
|
43. SHAKELINER |
44. CEDAR SHAKES |
45. LOG BEAM |
|
* 46. GUTTER |
* NOT INCLUDED IN BASIC SHELL PACKAGE |
